Verify that the PCB footprint, pitch and pin assignment match the connector drawing before production.
Do not exceed the specified current and voltage ratings; use appropriate trace width and copper thickness on the PCB.
Maintain correct mating alignment; avoid excessive force, twisting or bending of the connector and solder joints.
Follow recommended reflow or wave-solder profiles for the housing material to prevent deformation.
Keep connectors in a clean, dry environment; avoid contamination of the contact area by flux, dust, oil or moisture.
For harsh environments or special requirements (high mating cycles, thicker gold, special plating), choose customized versions to ensure long-term reliability.
